General Features
- The Ricoh MP 2553 can recover from sleep mode in less than 10 seconds and can print up to 25 monochrome pages per minute.
- With the standard 100-Sheet Automatic Reversing Document Feeder (ARDF), users can scan up to 79 color or monochrome images per minute. Use the internal finisher to add a professional touch to document sets and streamline workflow even more - without adding to the small footprint.
- Personalize the Home Screen with one-click icons for commonly used tasks, including copying, scanning and faxing. Use optional embedded software such as GlobalScan® or third-party vendor software to create custom workflows for your most complicated tasks.
- Our partnerships with industry-leading technology innovators allow access to a large selection of applications for content management and other business-critical tasks directly from the MFP.
- For misfeeds, the MP 2553 offers easy-to-follow animated guides that help users identify and resolve the source of the problem. Users can tilt the 9-inch control panel screen for easier viewing and more convenient access to system functions. Plus users can preview jobs to ensure accuracy prior to printing or scanning.
- The Ricoh MP 2553 features a a powerful 533 MHz processor, up to 1.5 GB RAM and a 250 GB HDD.
- It integrates seamlessly in almost any environment—including Windows, Macintosh, Citrix, SAP, UNIX, AS/400 and more.
- The icon-driven, one-click preset PCL6 user interface driver simplifies print jobs for crisp output at up to 600 dpi.
- Advanced administrative controls allow you to set quotas and limit output for specific users or workgroups. This can help your organization to reduce operating costs while encouraging more environmental awareness for long-term, sustainable savings.
Mobile Features
- The Ricoh MP 2553 integrates with Ricoh HotSpot Enterprise™, so mobile users can print directly to the MFP from laptops, smartphones and tablets without compromising speed, convenience or security.
- This powerful solution is designed to be behind your firewall, does not require print drivers for mobile devices and works seamlessly with cost recovery software.
- The MP 2553 can print from many mobile devices, including smartphones, tablets or laptops, without device-specific drivers for incredible on-the-go convenience.
- For organizations seeking even more secure mobile printing, the optional Ricoh HotSpot® MFP, or Ricoh HotSpot® Enterprise server software can be installed to help improve mobile productivity without compromising data, document or user security.
- Users can print JPEGs, TIFFs and PDFs using a USB drive or SD card right at the device without LAN access or native applications.
Scanner Features
- Scan in black-and-white or color in PDF, TIFF or JPEG formats. Then share them immediately via Scan-to-File/ Folder/URL/FTP/Email functionality.
- Compress file sizes for more complex scans and send them easily without compromising image quality.
- Distributed Scan Management (DSM) offers centralized scanning that automates many tasks while following specific preferences, permissions and rules that expedite delivery.
Productivity-Enhancing Features
- Spend less time looking for documents. The Ricoh MP 2553 offers optional embedded OCR, so users can retrieve documents quickly by searching for specific words in PDF text in up to 14 languages.
- This convenient feature can also detect blank pages in large jobs and remove them automatically to reduce waste. Plus connect to Ricoh’s optional Integrated Cloud Environment (ICE) solution and scan documents, share files and print on the go with incredible convenience from the MFP touchscreen.
Smart Operational Panel Features (Optional)
- Optional 10.1" Wide Super VGA Smart Operation Panel offers the functionality and performance of today’s smartphones and tablets. Featuring drag-and-drop, pinch-and-flick functionality and swipe scrolling, it allows users to quickly move from one task to the next with unprecedented ease.
- It includes convenient widgets for quick updates on the date, time and toner levels. The new panel also offers advanced Web Browser functionality on par with today’s personal computers.
- The new Quick User Interface feature simplifies the choices for the most frequently used functions for Copy, Scanner and Fax. They can be used with intuitive touch gestures, such as flicking to select addresses, and pinching to zoom in or pan out on a preview.
- For workgroups requiring enhanced feature functionality, it is easy to switch between the Quick User Interface functions and the traditional user interface.
Security Features
- The Ricoh MP 2553 includes user authentication to help prevent unauthorized access to key functions and proprietary information.
- Documents can be stored at the MFP and released after authorized users authenticate at the device with a user log-in name and password or with an ID card that’s swiped at the optional card reader.
- The device can also overwrite data on the hard drive automatically and offers encryption protection to help protect against hackers.
Fax Features
- Send or receive faxes electronically with Internet Faxing. Or, use LAN faxing to transmit directly from a PC.
- Super G3 faxing is available as well for quick delivery to conventional fax numbers.
- With the Remote Fax Option, users can send and receive fax documents from any connected device in your fleet – even those without fax options – by sending it through the Ricoh MP 2553. This minimizes phone line costs and additional fax boards.
Environmental Features
- Designed to be one of the lowest typical electricity consumption (TEC) values in the industry, the MP 2553 meets all new ENERGY STAR v2.0 criteria.
- Organizations can also program the device to power on or off during specified downtimes, including during weekends or lunch, to conserve even more energy.
Specyfikacja
ngine/Copier Specifications
Scanning
One-Dimensional Solid Scanning Through CCD
Simplex Paper Weight
11 – 34 lb. Bond (40 – 128 g/m²)
Printing Process
Single Laser Beam Scanning & Electrophotographic Printing
Toner
Dry, Dual Component
Copy Resolution
600 x 600 dpi
Quantity Indicator
Up to 999
First Copy Time
4.2 seconds
Recovery Time to Print Ready Mode
9.9 seconds
System Memory (std/max.)
1.5 GB RAM + 250 GB HDD
Original Type
Book/Sheet/Object
Maximum Original Size
Up to 11" x 17"
Paper Type
Plain Paper, Transparencies, Letterhead, Color Paper, Pre-Punched Paper, Labels, Envelopes, Cardstock, Recycled
Continuous Copying Speed
25 copies/minute (LTR)
Power Source
120V/60Hz/12A
TEC Value
1,332 Wh (Print/Scan)
Standard Paper Capacity
500 sheets x 1 tray, 550 sheets x 1 tray, and 100-Sheet Bypass Tray
Maximum Paper Capacity
3,150 sheets
Supported Paper Sizes
5.5" x 8.5" – 11" x 17" (A6 – A3)
Supported Paper Weights
14 – 28 lb. Bond (52 – 105 g/m²) (Duplex)
14 – 42 lb. Bond (52 – 157 g/m²) (Tray 1, 2 and Bypass)
Standard Output Tray Capacity
500 sheets
Maximum Output Capacity
1,600 sheets (Bridge Unit + 1 Bin + 1,000-Sheet Finisher)
Panel Size
5.5" x 8.5" – 11" x 17" (A5 – A3)
Stack Capacity
100 sheets
Reduction Ratios
25%, 50%, 65%, 73%, 78%, 85%, 93%, 100%
Enlargement Ratios
121%, 129%, 155%, 200%, 400%
Zoom
25% to 400% in 1% increments
Standard Features
Auto Magnification, Auto Paper Select, Auto Tray Switch, Booklet/Magazine Copy, Center/Border Erase, Chapters, Combine Mode, Cover Insertion, Directional Magnification, Document Server (3,000 File Capacity), Duplex, Electronic/Rotate Sorting, Full-Color VGA Touch Screen Control Panel, ID Card Copy, 8 Job Presets, 25 Job Programs, Negative/ Positive, OHP Slip Sheet, Sample Copy, Series Copy, Simple Screen, 1,000 User Codes, User Stamps
Dimensions (WxDxH)
23.1" x 25.7" x 32.6" (587 x 653 x 835 mm)
Printer Specifications (Standard)
Standard Interfaces
10Base-T/100/1000BaseTX Ethernet, USB 2.0
Optional Interfaces
IEEE 802.11a/b/g/n Wireless LAN & IEEE 1284 Parallel
Memory Capacity
Shared with Copier
Network Protocol
TCP/IP (IPv4, IPv6), IPX/SPX*
Network Operating Systems
Windows Vista/7/8/XP/Server 2003/ Server 2003R2/Server 2008/2008R2/Server 2012; Netware* 6.5 or later, Unix Filters for Sun Solaris, HP-UX,
SCO OpenServer, Red Hat Linux, IBM AIX, Mac OS X 10.5 or later, SAP R/3, NDPS Gateway, IBM iSeries/ AS/400® using OS/400 Host Print Transform, Citrix Presentation Server 4.5/Citrix Xen App 5.0, 6.0, 6.5
Utilities
@Remote, SmartDeviceMonitor, Device Manager NX, Web SmartDeviceMonitor, Web Image Monitor
Page Description Languages
Standard PCL5e/6 & XPS, Optional Adobe PostScript 3®
Print Resolution
Up to 600 dpi
Fonts for PCL5e/6
45 Scalable Fonts, 13 International Fonts
Fonts for PS3
136 PostScript Fonts
Standard Features
Sample/Locked/Hold/Stored Print
*Requires optional SD Card for Netware
Scanner Specifications (Standard)
Scanning Speed (B&W & Color LTR)
Embedded Scanning: 79/79 ipm (@ 300 dpi)
Scanning Resolution
600 dpi
Scan Area
Up to 11" x 17"
Standard Interfaces
10Base-T/100/1000BaseTX Ethernet
Optional Interfaces
IEEE 802.11a/b/g/n Wireless LAN
Protocol
TCP/IP, NCP*, SMB, SMTP, POP 3, LDAP, FTP, IMAP4
Memory Capacity
Shared with Copier
File Types
Single and Multi-Page TIFF/PDF, High Compression PDF, PDF/A and Single-Page JPEG
Standard Features
Embedded Scan-to-Email/Folder/URL, TWAIN and Color Scanning
*Requires optional SD Card for Netware
Fax Specifications (Option)
Resolution
200 x 200/100 dpi
400 x 400 dpi (optional)
Compression Method
MH, MR, MMR, JBIG
Scanning Speed
Less than 1 second (SEF)
Modem Speed
33.6 Kbps with Auto Fallback
Transmission Speed
G3: 3 seconds per page (MMR Compression)
G3: 2 seconds per page (JBIG Compression)
SAF Memory
4 MB standard/28 MB maximum
320 pages/2,240 pages
Group Dials
100 (max. 500 numbers per group)
Standard Features
Dual Access, Duplex Reception, Image Rotation, 1 Hour Backup, LAN-Fax Capability, Internet Faxing (T.37), IP Faxing (T.38), Fax Forwarding to E-Mail/HDD/Folder
Optional Features
Simultaneous Operation of up to 3 lines(G3 x 3)
Security Features (Standard)
DOSS, HDD Encryption, S/MIME, IPsec Communication, Locked Print Password Encryption, Address Book Encryption, SSL, User Authentication, Quota Setting/Account Limit, SNMP v3, SMTP over SSL and PDF encrypti
MP 2553SP/MP 3053SP/MP 3053AD/MP 3353SP/MP 3353AD
SPECYFIKACJA GŁÓWNA
OGÓLNE
Czas nagrzewania:
15 sekund
Prędkość wykonania pierwszej
kopii:
4,2 sekundy
Prędkość wydruku ciągłego:
25/30/30/33/33 stron na minutę
Pamięć:
Standardowo:
1 536/1 536/512/1 536/512 MB
Dysk twardy:
250 GB (Opcja)
Wymiary (szer. x gł. x wys.):
587 x 675 x 710 mm
Waga:
75 kg
Źródło zasilania:
220 - 240 V, 50/60 Hz
KOPIARKA
Proces kopiowania:
Skanowanie wiązką lasera i druk
elektrofotograficzny
Element skanujący:
Jednowymiarowe
ciągłe
skanowanie
za
pomocą CCD
Kopiowanie wielokrotne:
Do 999 kopii
Rozdzielczość:
300 dpi
Zoom:
Od 25% do 400% co 1%
DRUKARKA (MP 2553SP, MP 3053SP, MP 3353SP)
Język drukarki:
Standardowo: PCL5e, PCL6, XPS,
Bezpośredni wydruk PDF
Opcja: Adobe® PostScript® 3™
Rozdzielczość drukowania:
600 x 600 dpi
Interfejs:
Standardowo: USB 2.0, Gniazdo SD,
Karta
sieciowa
10
base-T/100
base-TX,
Ethernet 1000 Base-T
Opcja: dwukierunkowy 1284,
Bezprzewodowa sieć LAN (IEEE
802.11a/b/g/n), Bluetooth
Protokół sieciowy:
TCP/IP (IP v4, IP v6), IPX/SPX (Opcja)
Środowiska Windows®:
Windows® XP, Windows® Vista,
Windows® 7, Windows® 8, Windows®
Server 2003, Windows® Server
2003R2, Windows® Server 2008,
Windows® Server 2008R2, Windows®
Server 2012
Środowiska Mac OS:
Macintosh OS X v10.5 lub nowszy
Środowiska UNIX:
UNIX Sun® Solaris, HP-UX, SCO
OpenServer, RedHat® Linux, IBM®
AIX
Środowiska Novell® Netware®:
v6.5 (Opcja)
Środowiska SAP® R/3®:
SAP® R/3®
Inne obsługiwane środowiska:
Brama NDPS, AS/400® using OS/400
Host Print Transform, IBM iSeries
SKANER
Prędkość skanowania:
Pełnokolorowe: Maksymalnie 80
oryginałów na minutę
Mono: Maksymalnie 80 oryginałów na
minutę
Rozdzielczość:
Maksymalnie: 300 dpi
Rozmiar oryginału:
A3, A4, A5, B4, B5
Sterowniki standardowe:
Sieciowy TWAIN
Skanuj do:
E-mail, Folder, SMB, FTP, URL, NCP
FAKS (Opcja)
Sieć:
PSTN, PBX
Kompatybilność:
ITU-T (CCITT) G3
Rozdzielczość:
8 x 3,85 linii/mm, 200 x 100 dpi
8 x 7,7 linii/mm, 200 x 200 dpi
Prędkość transmisji:
G3: 2 sekund (200 x 100 dpi, JBIG)
Prędkość modemu:
Maksymalnie: 33,6 Kbps
Prędkość skanowania:
1 sek.
Pojemność pamięci:
Standardowo: 4 MB
Maksymalnie: 28 MB
OBSŁUGIWANY PAPIER
Zalecany rozmiar papieru:
Standardowa/e kaseta/y na papier: A3,
A4, A5, A6, B4, B5, B6
Taca ręczna: A3, A4, A5, A6, B4, B5,
B6
Pojemność wejściowa papieru:
Maksymalnie: 3 150 arkuszy
Pojemność wyjściowa papieru:
Maksymalnie: 1 600 arkuszy
Gramatura papieru:
Standardowa/e kaseta/y na papier: 52 -
157 g/m²
Taca ręczna: 52 - 157 g/m²
EKOLOGIA
Pobór mocy:
Maksymalnie: 1 600 W
Tryb gotowości: 152/152//152 W
Tryb uśpienia: 0,61/0,61//0,61 W
Współczynnik TEC (typowy pobór
energii
elektrycznej):
1
303/1
674//1
826
Wh
OPROGRAMOWANIE
Standardowo:
SmartDeviceMonitor, Web
SmartDeviceMonitor®, Web Image
Monitor
Opcjonalnie:
GlobalScan NX, Card Authentication
Package, Unicode Font Package for
SAP, Remote Communication Gate S
Pro
OPCJE
ADF
handle,
1
x
550-arkuszowa
kaseta
na
papier,
2
x
550-arkuszowa
kaseta
na papier, 2000-arkuszowa kaseta dużej pojemności, Zespół łącznika,
Finiszer, finiszer na 1 000 arkuszy, Finiszer wewnętrzny, finiszer na 1,000
arkuszy, Dziurkacz dla finiszera broszurującego, Dziurkacz dla finiszera
wewnętrznego, Wewnętrzna taca przesuwna, Taca jednopółkowa,
Podstawa
z
kółkami,
Szafka,
Opcja
Drukarka/Skaner,
Moduł
drukarki,
Opcja
rozszerzenia
o
skaner,
Dysk
twardy,
dwukierunkowy
1284,
Bezprzewodowa
sieć LAN (IEEE 802.11a/b/g/n), Bluetooth, Netware, PostScript3, moduł
Browsera,
konwerter
formatów
pliku,
interfejs
licznika,
uchwyt
na
czytnik
kart,
Moduł
zabezpieczenia
danych
przed
kopiowaniem,
Moduł
połączenia
faksu,
Dodatkowa linia Super G3, Pamięć faksu, opcja faksu, Unicode Font
Package for SAP, Moduł OCR, Wbudowany moduł czytnika kart
MATERIAŁY EKSPLOATACYJNE
Pojemność tonera:
Czarny: 11 000 wydruków
1
Dysk twardy jest opcją dla MP 3053AD i MP 3353AD.
W celu potwierdzenia dostępności modeli, opcji i oprogramowania
prosimy skontaktować się z lokalnym autoryzowanym dostawcą
produktów Nashuatec
